Spark 940 Bike – 2024

When you think of the perfect mountain bike, what comes to mind? For Scott, it’s the Spark 940. Why, you ask? Well, beyond the fact that it is fast, lightweight and ultra capable on all sorts of terrain, it’s just good lookin’. Short-travel trail bike? "Downcountry" rig? Occasional race bike? Whatever, call it what you want to call it. All they know is that this is one phenomenal mountain bike

Features

• Evo-Lap Technology – Thanks to extensive computer modeling, Scott optimized the carbon layers in all the parts of their frames. When the parts were bonded together in the first prototypes, the result was a super light and compact frame without sacrificing the stiffness, comfort or impact resistance
• Adjustable Head Angle – With the new Spark, you can adjust the head angle by .6 degrees slacker or steeper. This can be done without cutting cables or bleeding brakes. All you must do is disassemble the bar, rotate the headset cups 180 degrees, and reassemble
• Easy Shock Access – Accessing the shock via the bottom bracket area is facilitated through a hatch. This makes it easy to adjust rebound, compression, shock pressure, and for installing or replacing the cable for Scott’s TwinLoc Suspension System
• Patented Integrated Suspension Technology – Integrated into the frame of the bike, the rear shock is protected from dirt and debris, and the bike’s center of gravity is lowered for better handling and a more stable ride.
• Rear Axle Tool – Featuring a T25, T30 and a 6 allen key all in one, with these three options you can adjust all pivot hardware and nearly everything else there is to adjust on the bicycle
• Single Pivot Suspension Layout – The Spark’s suspension layout has a very specific and proven kinematic and less unsprung mass. Using a flex pivot in the seat stay is an ideal solution for bikes in this travel range. This allows Scott to keep a very lightweight system while still ensuring optimal suspension performance
• Weight – 29.76 lbs

Tech Specs

• Brakes

  • Brakes

    Shimano MT501 Disc

  • Rotor

    Shimano SM-RT54 CL / F&R 180mm

• Cockpit

  • Remote System

    Scott TwinLoc 2 Technology, Suspension & Dropper Remote, 3 Suspension modes

  • Stem

    Syncros DC 2.0, Syncros Cable Integration System, 0 degree rise / 6061 Alloy / 31.8mm / 1 1/8"

  • Handlebar

    Syncros Fraser 2.0 DC Alloy 6061 D.B., mini Rise / back sweep 8 degree / 760mm, Syncros Performance XC lock-on grips

  • Seatpost

    Syncros Duncan Dropper Post 2.5, 31.6mm / S & M size 125mm / L size 150mm / XL size 170mm

  • Headset

    Syncros – Acros Angle adjust & Cable Routing HS System, +-0.6 degree head angle adjustment, ZS56/28.6 – ZS56/40 MTB

• Drivetrain

  • Shifters

    SRAM SX Eagle Trigger

  • Rear Derailleur

    SRAM NX Eagle 12 Speed

  • Cassette

    SRAM SX-PG1210 / 11-50 T

  • Chain

    SRAM CN NX Eagle

  • Crankset

    SRAM X1 Eagle DUB, 55mm CL / 32T

  • Bottom Bracket

    SRAM DUB PF 92 MTB Wide / shell 41x92mm

• Frameset

  • Frame

    Spark Carbon HMF Mainframe with Alloy 6011 Swingarm, Integrated Suspension Technology, Flex Pivot / Adjustable head angle, Syncros Cable Integration System, BB92 / UDH Interface / 12x148mm with 55mm Chainline

• Other

  • Seat

    Syncros Tofino 2.5 Regular

• Suspension

  • Rear Shock

    RockShox Deluxe Select RL3 Trunnion, 3 modes / Lockout-Trail-Descend, Debon Air / Reb. Adj., Travel 120mm / T165X45mm

  • Fork

    RockShox Pike RL3 Air, Custom Charger 3-Mode Damper, 15x110mm Maxle Lite / 44mm offset / Tapered steerer, Lockout / Reb. Adj. / 130mm travel

• Wheels & Tires

  • Hub Front

    Formula CL-811 / 15x110mm

  • Hub Rear

    Formula CL-148S / 12x148mm, Syncros Axle w/Removable Lever, with 6mm Allen, T30 and T25 Tools

  • Rims

    Syncros X-30SE / 32H / 30mm, Tubeless ready

  • Tires

    Schwalbe Wicked Will 29×2.4" EVO, Super Ground / TLE / 67EPI / Addix Speed Grip

  • Spokes

    Stainless Black 15G / 1.8mm
