Tech Specs
- Brakes
-
Brake Rotor
Shimano RT86, 6-bolt, 203mm
-
Brake Rotor
Shimano RT86, 6-bolt, 180mm
-
Brake
Shimano XT M8200 4-piston hydraulic disc
-
- Cockpit
-
Stem
Bontrager Elite, 35mm, 0 degree, 45mm length
-
Handlebar
Race Face ERA, carbon, 35mm, 40mm rise, 800mm width
-
Grips
Trek Line Elite, lock-on
-
Saddle
Verse Short Pro, carbon rails, 145mm width
-
Seatpost
(Size S) Bontrager Line Dropper, 150mm travel, MaxFlow, internal routing, 34.9mm, 410mm length
-
Seatpost
(Size M) Bontrager Line Dropper, 170mm travel, MaxFlow, internal routing, 34.9mm, 450mm length
-
Seatpost
(Size L, XL, XXL) Bontrager Line Dropper, 200mm travel, MaxFlow, internal routing, 34.9mm, 515mm length
-
- Drivetrain
-
Rear Derailleur
Shimano XT M8250, long cage
-
Cassette
Shimano XT M8200, 10-51, 12 speed
-
Chain
Shimano Ultegra/XT M8100, 12 speed
-
Shifter
Shimano XT Di2 M8250, 12 speed
-
Crank
Shimano XT 8200, 30T, 55mm chainline, 170mm length
-
Bottom Bracket
Shimano BB-MT501 BSA
-
- Frameset
-
Frame
OCLV Mountain Carbon, internal storage, ZS headset, adjustable leverage rate, guided internal routing, interchangeable alloy rocker link, interchangeable lower shock mount, downtube guard, shuttle guard, BSA 73, ISCG 05, ABP, UDH, Boost148, adaptable travel 145mm-160mm
-
- Suspension
-
Fork
Fox Factory 36, Float EVOL air spring, GRIP X2 damper, 44mm offset, Boost 110, 15mm Kabolt X axle, 150mm travel
-
Shock
Fox Factory Float X, 205mm x 60mm
-
- Weight
-
Weight
33.25 lbs
-
- Wheels & Tires
-
Skewer Rear
Bontrager Switch thru axle, removable lever
-
Tire
Maxxis Minion DHF, tubeless ready, 3C, EXO+ casing, MAXXGRIP, folding bead, 29×2.5”
-
Tire
Maxxis Minion DHR II, tubeless ready, 3C, EXO+ casing, MAXXTERRA, folding bead, 29×2.5”
-
Wheel Front
Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15mm thru axle, 29”
-
Wheel Rear
Bontrager Line Comp 30, Tubeless Ready, Rapid Drive 108, 6-bolt, Shimano MicroSpline freehub, Boost148, 12mm thru axle, 29”
-
